There are bottlenecks when using sound and vibration measurement for production line, includes:
- Complex spectrum analysis
- Expertise in sound and vibration
- Simple operation and fully analysis
- Communicate with external equipment
- Analysis method compare to measurement item
- QC Criterion Setup
SV System Feature：
- Simple operation and fully analysis
- Improve quality, capacity and yield rate control.
- Expertise mode and operator mode makes setting up complex inspections a breeze.
- Communicate with external equipment by defined DIO or PLC
- Flexible Edit test procedure
- Operator can easily and correctly do measurement.
- Reporting Pass/Fail results of the inspection.
- Analyzing Yield rate and trend in database
- Flexible software architecture
- Customized module supported
Application：
Sound and vibration inspection for motor, engine and gearbox、Gluing condition inspection
SV System Specification：
|
Model number
|
SV-PXI
SV-PCI
SV-USB
|
|
Input power
|
100~240Vac 1A
|
|
Channel
|
1, 2, 3, 4, 8, 16
|
|
Input signal
|
IEPE Accelerometer, IEPE Microphone
|
|
Engine rpm
|
|
Edit test procedure
|
Support
|
|
Build test database
|
Support
|
|
QC Criterion Setup
|
Support
|
|
Supervisor mode
|
Support
|
|
User mode
|
Support
|
|
IO Definition
|
Support
|
|
External IO
|
DI*4, DO*4
|
|
PLC(Mitsubishi/FATAK)
|
|
Analysis function
|
Time domain Waveform
|
|
FFT
|
|
Power Spectrum
|
|
Frequency Response Function (FRF)
|
|
Octave
|
|
Order tracking
|
|
Eigen-frequency analysis (Belt, Gear box, Bearing)
|
|
Signal process
|
Filter
|
|
Integral, Differential
|
|
RMS, Mean, Peak,
|
|
Frequency Band power
|
|
FRF Band power
|
|
Peak frequency
|
|
QC Criterion Setup
|
Waveform threshold
|
|
Frequency band power
|
|
FRF Band power
|
|
Peak frequency
|
|
Support language
|
English, Traditional Chinese
|
Optional item：
|
Engine Tachometer
|
Chief ENG01
|
|
Engine Revolution Probe
|
Chief PB01
|
|
