Can Navigator

The best tools of CAN Bus measurement.

Easy to Use CAN Bus measurement：

With high-speed transmission and fault-tolerant features, CAN Bus has become the standard interface for vehicle control. CAN Bus is increasingly important in the field of automatic control and measurement, but the complexity of coding can make it difficult to understand. Existing CAN measurement systems are often complex and expensive, with users paying 100% for the use of only 20% of the functions! CAN Navigator is a cost-effective CAN Bus measurement system that will greatly simplify the use of the CAN Bus for beginners and experienced engineers.

System features：

Graphic control interface that is easy to learn and use.
Flexible signal triggering and data filtering.
Flexibility to customize function hotkeys to easily import production line.
Recorded data can be edited and played back.
Decode the signal directly into physical quantity.
An indispensable USB interface that is easy to carry.
Fully functional. Cost Effective.

Applications：

Automotive electronic components research and development / test.
Production line CAN Bus communication testing.
Depot vehicle communication verification.School or research institutes CAN Bus development.

CAN Navigator Specification：

Model	CAN Navigator

Input Power	USB Support , don’t need external power
Interface	USB 2.0
Port	One or two
BAUD Rate	40 kb/s ~ 1Mb/s
CAN Interface	High speed CAN
Protocol	CAN 2.0A (11-bit) / extended CAN 2.0B (29-bit)
Pattern Editor	Recorded data can be edited and replayed
	ID and Data can be edited
	36 hotkey can send Pattern info
	Custom transmission frequency and time interval
Frame Filter	CAN measurement done in a timely manner of the ID or Data filter.
	When ID or Data triggered, automatically show messages or start transmission Pattern
Frame Measurement	Can be set to send or receive
	Timely receive ID and Frame Data
	Expected to facilitate the observation can be set to filter ID or Data
	High-speed data storage, applications to do post-mortem analysis
	Can detect Error Frame
	Can set CAN Channel info, conversion Frame to physical quantities
	Immediate display of physical quantities graph
	The loadable CAN file does Frame transmission
	Can be set to send the number and time interval of the transmission
	Can directly edit, transmit physical quantities.
Frame Analysis	Analysis CAN data
	Frame Data reply function
	ID or Data filtering function
	Physical quantity graphs
	Can output ASCII data files or Patten format file
Language	English, Traditional Chinese
Computer Requirements	CPU:P4, RAM:1GB, HD:1GB, USB 2.0
Screen requirements	1280*800 resolution
Operating system	Windows XP, VISTA, WIN 7

If you are interesting in the Can Navigator, please download the catalog and Contact Us now. A sales representative will contact with you as soon as possible.
